GLR Overhead

Price 100000.0 INR/ Number

Get a Price/Quote

MOQ : 1 Unit

GLR Overhead Specification

Power
NA Watt (w)

Condition
New

Product Type
Distillation Unit

General Use
Industrial (Commercial)

Material

Computerized
Yes

Automatic
Yes

PLC Control
Yes

Mixer Type
Other

Voltage
220/440 Volt (v)

Dimension (L*W*H)
1200 x 900 x 2500 Millimeter (mm)

Feature
Low Energy Consumption

Warranty
Yes

GLR Overhead Trade Information

Minimum Order Quantity
1 Unit

FOB Port
Vadodara

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
1 Week

Main Domestic Market
All India

Certifications
ISO 9001:2015 Certified

About GLR Overhead

GLR (Glass Lined Reactor) overhead assemblies are

specialized, modular, borosilicate glass systems installed atop chemical reactors for distillation, condensation, and reflux processes under atmospheric or vacuum conditions. Designed for 500 Ltr to 10000 KL reactors, they feature a vapor column, condenser, reflux divider, receiver, and, for large scale, often a glass shell-and-tube heat exchanger.

Key Components of a GLR Overhead Assembly

Vapor Column: Packed or hollow, for separating vapors.
Condensers: Primary and secondary (vent) condensers, often coil or shell-and-tube type, to liquefy vapours.
Reflux/Distillation Unit: Controls the return of condensed material to the reactor or to the receiver.
Receivers: Flasks or tanks to collect products, often designed to maintain vacuum during emptying.
Structure: Adaptor plate, bellow with flange, piping, and support structures.

Applications and Features

Versatility: Used for distillation, reaction, and separation processes.
Safety: Designed for vacuum operations, with specific attention to pressure equalization.
Customization: Tailored based on reactor size and process requirements.
Material: Borosilicate glass ensures high corrosion resistance for aggressive chemical reactions.

These assemblies are widely used in chemical, pharmaceutical, and API industries, especially in Vadodara, Gujarat, which is a major hub for manufacturers of these systems.

Reactor Capacity	Heat Exchange Area (m2)	Shell & Tube Heat Exchanger - Glass (m2)	Shell & Tube Heat Exchanger - SiC (m2)	Vent Condenser Glass (m2)	Feed Vessel (Lts)	Receiver Vessel (Lts)	Vapour Line (DN)
63	0.53	2.5	-	0.3	20	2x20	80
100	0.85	2.5	-	0.6	50	2x50	80
160	1.23	4	-	1	50	2x50	80
250	1.66	5	-	1	100	2x100	80
400	2.4	8	2.5	1	100	2x100	100
500	2.56	8	2.5	1.5	100	2x100	150
630	3.1	10	3.2	1.5	100	2x100	150
1000	4.56	12.5	4	1.5	200	2x200	225
1600	6	16	5	1.5	200	2x200	225
2000	7.1	16	5	1.5	200	2x200	225
2500	8.3	20	6.3	1.5	200	2x200	225
3000	9.1	20	6.3	1.5	200	2x200	225
4000	11.7	25	8	1.5	200	2x200	200
5000	13.1	25	8	2.5	200	2x200	300
6300	16.2	25	8	4	200	2x200	300
